Low-Carbon Iron Wire 80 X 100mm Gabion weave 2x1x1m Wire Mesh hexagonal Hole
Galvanized gabion mesh
Wire diameter:2.7/3.7mmedge Wire:3.4/4.4mm
Tie wire:2.2/3.2mmSize: 2x1x1m/3x1x1m
Mesh size:80x100mm/100x120mm
Zinc coating:40-60g/㎡
High zinc :250g/㎡
Gabion mesh construction Material:
1) Galvanized steel wire: diameter 2.0MM-4.0MM, tensile strength >380Mpa, zinc: 200g / m2.
2) Zinc 5% Aluminum - wire diameter 1.0MM-3.0MM, tensile strength >380Mpa.
3) Coated galvanized steel wire: low carbon steel wire, pvc coated
4) Zinc 5% Aluminum
Gabion mesh construction treatment:
Hot-dipped galvanized, electric galvanized, galvanized aluminum alloy or PVC coated, etc.
| Opening (mm) | Wire Diameter (Metal Wire) (mm) | Wire Diameter (PVC Coated)/ Inner/Outside (mm) | Size(m) | Strands |
| 60X80 | φ2.0-2.8 | φ2.0/3.0-2.5/3.5 | 1x1x0.3 1x1x0.5
2x1x0.3 2x1x0.5
2x1x1 4x2x1
6x2x0.3 6x2x1
As your request | 3 |
| 80X100 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 | 3 |
| 80X120 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 | 3 |
| 100X120 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 | 3 |
| 100X150 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 | 3 |
| 120X150 | φ2.0-4.0 | φ2.0/3.0-3.0/4.0 | 3 |
| gabion specifications | Mesh hole modle |
| | 8x10cm | 6x8cm |
| Length(m) | Width(m) | Height(m) | Galvanized or PVC coated | Galvanized or PVC coated |
| | Mesh diameter | Zinc | Mesh diameter | Zinc |
| 2 | 1 | 1 | 2.7mm | >245g/m² | 2.0mm | >215g/m² |
| 3 | 1 | 1 | Side wire diameter | Zinc | Side wire diameter | Zinc |
| 4 | 1 | 1 | 3.4mm | >265g/² | 2.7mm | >245g/m² |
| 6 | 1 | 1 | Binding wire diameter of 2.7m | | |
FAQ
1. What's your advantage?
Honest business with competitive price and professional service on export process.
2. Can I customize the products?
Yes, as long as provide specifications, drawings, can only do what you want products.
3. How can I know how my order is bheing done?
We will inspect and test all items in order to avoid damage and missing parts before shipping. The detailed inspection pictures of the order will be sent to you for your confirmation before delivery.
4. Where are you? Can I visit you?
Sure, we are in Anping, Hebei Province. There are many flights from Shanghai, Guangzhou to our city. Please contact us to make an appointment.
